Rectangular Inserts
Cinch’s C-ENX rectangular inserts are key components used in rectangular connectors to create secure and reliable electrical connections. These inserts house the contact pins and ensure proper alignment within the connector housing. Designed for easy integration and featuring a modular design, these inserts are ideal for aerospace applications, adhering to the EN 4644 standard.
Attribute Filters
Insert Size
Insert Type
Insert Arrangement
Environmental Sealing
Insert Keying
326 Product(s)
Show Filters
Hide Filters
| Product | Brand | Insert Size | Contacts | Insert Type | Insert Arrangement |
|---|---|---|---|---|---|
| c-enx | Insert for C-ENX A | Not Included | Pin | 2 x size 15 or 16 contacts | 2 x size 12 contacts | |
| c-enx | Insert for C-ENX A | Not Included | Socket | 2 x size 15 or 16 contacts | 2 x size 12 contacts | |
| c-enx | Insert for C-ENX A | Not Included | Pin | 3 x size 20 contacts | 6 x size 15 or 16 contacts | |
| c-enx | Insert for C-ENX A | Not Included | Socket | 3 x size 20 contacts | 6 x size 15 or 16 contacts | |
| c-enx | Insert for C-ENX A | Not Included | Pin | 8 x size 22 contacts | 3 x size 20 contacts | 3 x size 15 or 16 contacts | |
| c-enx | Insert for C-ENX A | Not Included | Socket | 8 x size 22 contacts | 3 x size 20 contacts | 3 x size 15 or 16 contacts | |
| c-enx | Insert for C-ENX A | Not Included | Pin | 14 x size 20 contacts | |
| c-enx | Insert for C-ENX A | Not Included | Socket | 14 x size 20 contacts | |
| c-enx | Insert for C-ENX A | Not Included | Pin | 12 x size 22 contacts | 5 x size 20 contacts | |
| c-enx | Insert for C-ENX A | Not Included | Socket | 12 x size 22 contacts | 5 x size 20 contacts | |
| c-enx | Insert for C-ENX A | Not Included | Pin | 1 x size 5 coax contact | |
| c-enx | Insert for C-ENX A | Not Included | Socket | 1 x size 5 coax contact | |
| c-enx | Insert for C-ENX A | Not Included | Pin | 1 x size 5 power contact | |
| c-enx | Insert for C-ENX A | Not Included | Socket | 1 x size 5 power contact | |
| c-enx | Insert for C-ENX A | Not Included | Pin | 20 x size 22 contacts | |
| c-enx | Insert for C-ENX A | Not Included | Socket | 20 x size 22 contacts | |
| c-enx | Insert for C-ENX A | Not Included | Pin | 2 x size 15 or 16 contacts | 2 x size 12 contacts | |
| c-enx | Insert for C-ENX A | Not Included | Pin | 3 x size 20 contacts | 6 x size 15 or 16 contacts | |
| c-enx | Insert for C-ENX A | Not Included | Pin | 8 x size 22 contacts | 3 x size 20 contacts | 3 x size 15 or 16 contacts | |
| c-enx | Insert for C-ENX A | Not Included | Pin | 14 x size 20 contacts | |
| c-enx | Insert for C-ENX A | Not Included | Pin | 12 x size 22 contacts | 5 x size 20 contacts | |
| c-enx | Insert for C-ENX A | Not Included | Pin | 1 x size 5 coax contact | |
| c-enx | Insert for C-ENX A | Not Included | Pin | 1 x size 5 power contact | |
| c-enx | Insert for C-ENX A | Not Included | Pin | 20 x size 22 contacts | |
| c-enx | Insert for C-ENX A | N/A | N/A | Blank insert |
Catalog
C-ENXAE04PA
C-ENX A Size Insert
Pin
Enviromental
Interfacial Seal and Rear Grommet
2X Size 16 Contact
2X Size 12 Contacts
Pin
Enviromental
Interfacial Seal and Rear Grommet
2X Size 16 Contact
2X Size 12 Contacts
C-ENXAE04SA
C-ENX A Size Insert
Socket
Enviromental
Interfacial Seal and Rear Grommet
2X Size 16 Contact
2X Size 12 Contacts
Socket
Enviromental
Interfacial Seal and Rear Grommet
2X Size 16 Contact
2X Size 12 Contacts
C-ENXAE09PA
C-ENX A Size Insert
Pin
Enviromental
Interfacial Seal and Rear Grommet
3X Size 20 Contacts
6X Size 16 Contacts
Pin
Enviromental
Interfacial Seal and Rear Grommet
3X Size 20 Contacts
6X Size 16 Contacts
C-ENXAE09SA
C-ENX A Size Insert
Socket
Enviromental
Interfacial Seal and Rear Grommet
3X Size 20 Contacts
6X Size 16 Contacts
Socket
Enviromental
Interfacial Seal and Rear Grommet
3X Size 20 Contacts
6X Size 16 Contacts
C-ENXAE14MPA
C-ENX A Size Insert
Pin
Enviromental
Interfacial Seal and Rear Grommet
8X Size 22 Contacts
3X Size 20 Contacts
3X Size 16 Contacts
Pin
Enviromental
Interfacial Seal and Rear Grommet
8X Size 22 Contacts
3X Size 20 Contacts
3X Size 16 Contacts
C-ENXAE14MSA
C-ENX A Size Insert
Socket
Enviromental
Interfacial Seal and Rear Grommet
8X Size 22 Contacts
3X Size 20 Contacts
3X Size 16 Contacts
Socket
Enviromental
Interfacial Seal and Rear Grommet
8X Size 22 Contacts
3X Size 20 Contacts
3X Size 16 Contacts
C-ENXAE14PA
C-ENX A Size Insert
Pin
Enviromental
Interfacial Seal and Rear Grommet
14X Size 20 Contacts
Pin
Enviromental
Interfacial Seal and Rear Grommet
14X Size 20 Contacts
C-ENXAE14SA
C-ENX A Size Insert
Socket
Enviromental
Interfacial Seal and Rear Grommet
14X Size 20 Contacts
Socket
Enviromental
Interfacial Seal and Rear Grommet
14X Size 20 Contacts
C-ENXAE17PA
C-ENX A Size Insert
Pin
Enviromental
Interfacial Seal and Rear Grommet
12X Size 22 Contacts
5X Size 20 Contacts
Pin
Enviromental
Interfacial Seal and Rear Grommet
12X Size 22 Contacts
5X Size 20 Contacts
C-ENXAE17SA
C-ENX A Size Insert
Socket
Enviromental
Interfacial Seal and Rear Grommet
12X Size 22 Contacts
5X Size 20 Contacts
Socket
Enviromental
Interfacial Seal and Rear Grommet
12X Size 22 Contacts
5X Size 20 Contacts
C-ENXAE1C1PA
C-ENX A Size Insert
Pin
Enviromental
Interfacial Seal and Rear Grommet
1X Size 5 Coax Contact
Pin
Enviromental
Interfacial Seal and Rear Grommet
1X Size 5 Coax Contact
C-ENXAE1C1SA
C-ENX A Size Insert
Socket
Enviromental
Interfacial Seal and Rear Grommet
1X Size 5 Coax Contact
Socket
Enviromental
Interfacial Seal and Rear Grommet
1X Size 5 Coax Contact
C-ENXAE1P1PA
C-ENX A Size Insert
Pin
Enviromental
Interfacial Seal and Rear Grommet
1X Size 5 Power Contact
Pin
Enviromental
Interfacial Seal and Rear Grommet
1X Size 5 Power Contact
C-ENXAE1P1SA
C-ENX A Size Insert
Socket
Enviromental
Interfacial Seal and Rear Grommet
1X Size 5 Power Contact
Socket
Enviromental
Interfacial Seal and Rear Grommet
1X Size 5 Power Contact
C-ENXAE20PA
C-ENX A Size Insert
Pin
Enviromental
Interfacial Seal and Rear Grommet
20X Size 22 Contacts
Pin
Enviromental
Interfacial Seal and Rear Grommet
20X Size 22 Contacts
C-ENXAE20SA
C-ENX A Size Insert
Socket
Enviromental
Interfacial Seal and Rear Grommet
20X Size 22 Contacts
Socket
Enviromental
Interfacial Seal and Rear Grommet
20X Size 22 Contacts
C-ENXAH04PA
C-ENX A Size Insert
Pin
Half
Rear Grommet and No Interfacial Seal
2X Size 16 Contact
2X Size 12 Contacts
Pin
Half
Rear Grommet and No Interfacial Seal
2X Size 16 Contact
2X Size 12 Contacts
C-ENXAH09PA
C-ENX A Size Insert
Pin
Half
Rear Grommet and No Interfacial Seal
3X Size 20 Contacts
6X Size 16 Contacts
Pin
Half
Rear Grommet and No Interfacial Seal
3X Size 20 Contacts
6X Size 16 Contacts
C-ENXAH14MPA
C-ENX A Size Insert
Pin
Half
Rear Grommet and No Interfacial Seal
8X Size 22 Contacts
3X Size 20 Contacts
3X Size 16 Contacts
Pin
Half
Rear Grommet and No Interfacial Seal
8X Size 22 Contacts
3X Size 20 Contacts
3X Size 16 Contacts
C-ENXAH17PA
C-ENX A Size Insert
Pin
Half
Rear Grommet and No Interfacial Seal
12X Size 22 Contacts
5X Size 20 Contacts
Pin
Half
Rear Grommet and No Interfacial Seal
12X Size 22 Contacts
5X Size 20 Contacts
C-ENXAH1C1PA
C-ENX A Size Insert
Pin
Half
Rear Grommet and No Interfacial Seal
1X Size 5 Coax Contact
Pin
Half
Rear Grommet and No Interfacial Seal
1X Size 5 Coax Contact
C-ENXAH1P1PA
C-ENX A Size Insert
Pin
Half
Rear Grommet and No Interfacial Seal
1X Size 5 Power Contact
Pin
Half
Rear Grommet and No Interfacial Seal
1X Size 5 Power Contact
