Stacking Connectors
Cinch stacking connectors provide versatile and durable solderless connections, ideal for various electronic applications, ensuring reliable electrical connections through mechanical pressure with over 100 compression cycles.
Attribute Filters
Fastener
No. of Positions
Alignment
Height (mm)
Height (in)
Min Compression Force (kg)
Min Compression Force (lb)
Rows
12 Products
Show Filters
Hide Filters
| Product | Brand | Connector Type | Fastener | No. of Positions | Alignment | Height (mm) | Min Compression Force (kg) | Min Operating Temp. (°C) | Max Operating Temp. (°C) | Rows |
|---|---|---|---|---|---|---|---|---|---|---|
| Cin::APSE | Stacking Compression | 2x no.2 Thru Holes (dia. 0.090in) | 25 | Holes | 3.18 | 1.8 | -55 | 125 | 2 | |
| Cin::APSE | Stacking Compression | 2x no.2 Thru Holes (dia. 0.090in) | 25 | Holes | 6.35 | 1.8 | -55 | 125 | 2 | |
| Cin::APSE | Stacking Compression | 2x no.2 Thru Holes (dia. 0.090in) | 25 | Pins | 3.18 | 1.8 | -55 | 125 | 2 | |
| Cin::APSE | Stacking Compression | 2x no.2 Thru Holes (dia. 0.090in) | 25 | Pins | 6.35 | 1.8 | -55 | 125 | 2 | |
| Cin::APSE | Stacking Compression | 2x no.2 Thru Holes (dia. 0.090in) | 51 | Pins | 3.18 | 3.6 | -55 | 125 | 2 | |
| Cin::APSE | Stacking Compression | 2x no.2 Thru Holes (dia. 0.090in) | 51 | Pins | 6.35 | 3.6 | -55 | 125 | 2 | |
| Cin::APSE | Stacking Compression | 2x no.2 Thru Holes (dia. 0.090in) | 51 | Holes | 3.18 | 3.6 | -55 | 125 | 2 | |
| Cin::APSE | Stacking Compression | 2x no.2 Thru Holes (dia. 0.090in) | 51 | Holes | 6.35 | 3.6 | -55 | 125 | 2 | |
| Cin::APSE | Stacking Compression | 4x no.2-56 Tapped Insert | 249 | Pins | 7.04 | 17.6 | -55 | 125 | 5 | |
| Cin::APSE | Stacking Compression | 4x no.4 Thru Holes (dia. 0.124in) | 249 | Holes | 7.04 | 17.6 | -55 | 125 | 5 | |
| Cin::APSE | Stacking Compression | 3x no.4 Thru Holes (dia. 0.124in) | 166 | Pins | 7.04 | 11.8 | -55 | 125 | 5 | |
| Cin::APSE | Stacking Compression | 2x no.4 Thru Holes (dia. 0.124in) | 83 | Pins | 7.04 | 5.9 | -55 | 125 | 5 |
Drawing
3800520001
CIN::APSE Stacking connector with 25 positions dispersed in 2 rows. The connector height is 0.125" (3.18 mm) and attaches to a PCB or components using 2x #2 Thru Holes (Ø 0.090”) for fasteners. Positioning features are located on the connector. The compression contacts bond to gold plated pads on the corresponding PCB or component.
3800520002
CIN::APSE Stacking connector with 25 positions dispersed in 2 rows. The connector height is 0.250" (6.35 mm) and attaches to a PCB or components using 2x #2 Thru Holes (Ø 0.090”) for fasteners. Positioning features are located on the connector. The compression contacts bond to gold plated pads on the corresponding PCB or component.
3800520004
CIN::APSE Stacking connector with 25 positions dispersed in 2 rows. The connector height is 0.125" (3.18 mm) and attaches to a PCB or components using 2x #2 Thru Holes (Ø 0.090”) for fasteners. Positioning features are located on the connector. The compression contacts bond to gold plated pads on the corresponding PCB or component.
3800520005
CIN::APSE Stacking connector with 25 positions dispersed in 2 rows. The connector height is 0.250" (6.35 mm) and attaches to a PCB or components using 2x #2 Thru Holes (Ø 0.090”) for fasteners. Positioning features are located on the connector. The compression contacts bond to gold plated pads on the corresponding PCB or component.
3800520013
CIN::APSE Stacking connector with 51 positions dispersed in 2 rows. The connector height is 0.125" (3.18 mm) and attaches to a PCB or components using 2x #2 Thru Holes (Ø 0.090”) for fasteners. Positioning features are located on the connector. The compression contacts bond to gold plated pads on the corresponding PCB or component.
3800520014
CIN::APSE Stacking connector with 51 positions dispersed in 2 rows. The connector height is 0.250" (6.35 mm) and attaches to a PCB or components using 2x #2 Thru Holes (Ø 0.090”) for fasteners. Positioning features are located on the connector. The compression contacts bond to gold plated pads on the corresponding PCB or component.
3800520016
CIN::APSE Stacking connector with 51 positions dispersed in 2 rows. The connector height is 0.125" (3.18 mm) and attaches to a PCB or components using 2x #2 Thru Holes (Ø 0.090”) for fasteners. Positioning features are located on the connector. The compression contacts bond to gold plated pads on the corresponding PCB or component.
3800520017
CIN::APSE Stacking connector with 51 positions dispersed in 2 rows. The connector height is 0.250" (6.35 mm) and attaches to a PCB or components using 2x #2 Thru Holes (Ø 0.090”) for fasteners. Positioning features are located on the connector. The compression contacts bond to gold plated pads on the corresponding PCB or component.
3800520038
CIN::APSE Stacking connector with 249 positions dispersed in 5 rows. The connector height is 0.277" (7.04 mm) and attaches to a PCB or components using 4x #2-56 Tapped Insert for fasteners. Positioning features are located on the connector. The compression contacts bond to gold plated pads on the corresponding PCB or component.
3800520042
CIN::APSE Stacking connector with 249 positions dispersed in 5 rows. The connector height is 0.277" (7.04 mm) and attaches to a PCB or components using 4x #4 Thru Holes (Ø 0.124”) for fasteners. Positioning features are located on the connector. The compression contacts bond to gold plated pads on the corresponding PCB or component.
3900520008
CIN::APSE Stacking connector with 166 positions dispersed in 5 rows. The connector height is 0.277" (7.04 mm) and attaches to a PCB or components using 3x #4 Thru Holes (Ø 0.124”) for fasteners. Positioning features are located on the connector. The compression contacts bond to gold plated pads on the corresponding PCB or component.
3900520017
CIN::APSE Stacking connector with 83 positions dispersed in 5 rows. The connector height is 0.277" (7.04 mm) and attaches to a PCB or components using 2x #4 Thru Holes (Ø 0.124”) for fasteners. Positioning features are located on the connector. The compression contacts bond to gold plated pads on the corresponding PCB or component.
